InverFlow Plus Inground Variable Speed Pump

InverFlow Plus Inground Variable Speed Pump by Madimack

Madimack’s InverFlow Plus is delivering enhanced power and superior performance alongside the energy-saving benefits of full-inverter technology.

Operating whisper-quietly at speeds as low as 33dB, it features Wi-Fi connectivity for effortless control, Skimmer Mode for a pristine pool surface and a market-leading 5-year warranty. The InverFlow Plus sets a new benchmark in efficiency, reliability, and convenience.

Trouver un magasin

- Available horsepower: 1HP | 1.5HP | 2HP
- Running Amps (115v/230v) 1HP :8.3 – 4.6 | 1.5HP: 8.9 – 5.9 | 2HP: 9.6 – 6.5
- Débit Qmax – GPM 1HP :112 | 1.5HP :125 | 2HP : 136
- Dimensions (Inch) 21” 7/16’ x 6” 5/8’ x 9” 15/16’
- Dimensions (mm) 590 x 255 x 325
- Weight (lbs) 32lb (2HP 34lb)
- Weight (kg) 14.5kg (2HP 15.5kg)
- Pipe connections (inlet/outlet) 2″ BSP
- Noise level 30% Speed 1HP: 32.9 | 1.5HP :35.8 | 2HP: 38.3
- Noise level 100% Speed 1HP :56.1 | 1.5HP :56.7| 2HP: 57.4
- Wi-Fi Connectivity
- *Specifications displayed refer to 230v supply and can vary with voltage fluctuations please visit www.madimack.com for further specifications
- 4 Timers For Daily Operation

  Full control capabilities, with multi speed and multi timer function
- Active Energy Monitor

  Monitor and manage operation efficiency
- Advanced Sound Suppression Technology

  Quiet operation down to 33 dB
- DC Brushless Motor

  Permanent magnetic motor for long lasting energy efficiency
- Dual Voltage

  Enabling flexible installation and ensure consistent performance regardless of the voltage
- InverMAC Technology

  Enhanced inverter motor for efficient performance and motor speed control
- Running Capacity From 30%~100%

  "Full inverter technology for maximum control—30%−100% set points"
- Skimmer/Boost Mode

  Activates for 5 minutes every hour to optimize surface cleaning efficiency
- Wi-Fi Capabilities

  Control your pump operation remotely

Features
- 4 Timers For Daily Operation

  Full control capabilities, with multi speed and multi timer function
- Active Energy Monitor

  Monitor and manage operation efficiency
- Advanced Sound Suppression Technology

  Quiet operation down to 33 dB
- DC Brushless Motor

  Permanent magnetic motor for long lasting energy efficiency
- Dual Voltage

  Enabling flexible installation and ensure consistent performance regardless of the voltage
- InverMAC Technology

  Enhanced inverter motor for efficient performance and motor speed control
- Running Capacity From 30%~100%

  "Full inverter technology for maximum control—30%−100% set points"
- Skimmer/Boost Mode

  Activates for 5 minutes every hour to optimize surface cleaning efficiency
- Wi-Fi Capabilities

  Control your pump operation remotely
Specifications
- Available horsepower: 1HP | 1.5HP | 2HP
- Running Amps (115v/230v) 1HP :8.3 – 4.6 | 1.5HP: 8.9 – 5.9 | 2HP: 9.6 – 6.5
- Débit Qmax – GPM 1HP :112 | 1.5HP :125 | 2HP : 136
- Dimensions (Inch) 21” 7/16’ x 6” 5/8’ x 9” 15/16’
- Dimensions (mm) 590 x 255 x 325
- Weight (lbs) 32lb (2HP 34lb)
- Weight (kg) 14.5kg (2HP 15.5kg)
- Pipe connections (inlet/outlet) 2″ BSP
- Noise level 30% Speed 1HP: 32.9 | 1.5HP :35.8 | 2HP: 38.3
- Noise level 100% Speed 1HP :56.1 | 1.5HP :56.7| 2HP: 57.4
- Wi-Fi Connectivity
- *Specifications displayed refer to 230v supply and can vary with voltage fluctuations please visit www.madimack.com for further specifications
